Fast ace AHX12RV Forks

FastAce AHX12RV 3.0 Front Forks – Premium Suspension Upgrade

Elevate your electric dirt bike’s front suspension with the FastAce AHX12RV 3.0 Forks — engineered for aggressive trail riding, jumps, and varied terrain. Designed to fit popular eMoto platforms like Sur-Ron, Talaria, and E-Ride Pro, these forks deliver outstanding adjustability, durability, and ride quality.

Key Specifications

• Travel: 200 mm

• Stanchion Diameter: 37 mm

• Axle: 20 × 110 mm Boost (M14 × P1.5, 170 mm length)

• Steerer Tube: 1-1/8" straight

• Spring Type: Coil spring (standard 60 lb)

• Damping Adjustments: 18 clicks High-Speed Compression, 18 clicks Low-Speed Compression, 18 clicks Rebound

• Brake Mount: Post-mount 203 mm (supports rotors up to 223 mm)

• Maximum Tire Width: ~67 mm

• Offset: 47 mm (27.5") / 57 mm (29")

• Ride Height (Axle to Crown): ~582 mm (27.5") / ~602 mm (29")

• Material: High-strength 2000 series aluminum alloy legs and plates

• Crown: Forged construction for enhanced durability

Features & Benefits

• Fully adjustable compression and rebound damping to fine-tune your ride

• Heavy-duty coil spring and oil damping system designed to absorb rough landings and aggressive terrain

• Compatible with a range of eMoto models, including popular electric dirt bikes

• Supports larger brake rotors for enhanced stopping power

• Wide tire clearance accommodates up to ~67 mm width tires

• Robust forged crown and aluminum construction ensure long-term strength and reliability

• Configurable offset supports multiple wheel sizes (26", 27.5", 29")

Ideal For

• Trail and freeride riders seeking improved front-end control and comfort

• E-moto enthusiasts upgrading from stock suspension for better performance

• Riders who switch between different wheel sizes and tire widths

• Anyone demanding durable, adjustable forks for aggressive riding

Important Notes

• Coil spring design means no air chamber; preload is managed through spring selection and damping settings

• Periodic maintenance recommended to keep seals and damping performance optimal under heavy use

• Proper spring rate and damping adjustment based on rider weight and terrain is essential for best results
